Associated Spring Raymond - 9.14mm OD, 1.5mm Wire, 17.53mm Free Length, Compression Spring - 111.62 Lb Spring Rating, 70.77 N Max Work Load, Stainless Steel
Item #: 69051852
Brand: Associated Spring Raymond
Model #: C03600590690S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 9.14 |
| Outside Diameter (Decimal Inch) | 0.3600 |
| Free Length (mm) | 17.53 |
| Free Length (Decimal Inch) | 0.6900 |
| Spring Rate Pounds per Inch (Pounds) | 111.6200 |
| Maximum Work Load (N) | 70.76999664 |
| Solid Height (mm) | 11.63 |
| Solid Height (Decimal Inch) | 0.4580 |
| Material | Stainless Steel |
| Wire Size (mm) | 1-1/2 |
| Wire Size (Decimal Inch) | 0.0590 |
