Associated Spring Raymond - 9.14mm OD, 1.3mm Wire, 2-3/4" Free Length, Compression Spring - 16.2 Lb Spring Rating, 72.68 N Max Work Load, Music Wire
Item #: 69051092
Brand: Associated Spring Raymond
Model #: C03600512750M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 9.14 |
| Outside Diameter (Decimal Inch) | 0.3600 |
| Free Length (mm) | 69.85 |
| Free Length (Decimal Inch) | 2-3/4 |
| Spring Rate Pounds per Inch (Pounds) | 16.2000 |
| Maximum Work Load (N) | 72.68000031 |
| Solid Height (mm) | 30.28 |
| Solid Height (Decimal Inch) | 1.1920 |
| Material | Music Wire |
| Wire Size (mm) | 1.30 |
| Wire Size (Decimal Inch) | 0.0510 |
