Associated Spring Raymond - 9.14mm OD, 1.2mm Wire, 35.05mm Free Length, Compression Spring - 20.7 Lb Spring Rating, 38.12 N Max Work Load, Stainless Steel
Item #: 69050060
Brand: Associated Spring Raymond
Model #: C03600471380X
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Compression |
Outside Diameter (mm) | 9.14 |
Outside Diameter (Decimal Inch) | 0.3600 |
Free Length (mm) | 35.05 |
Free Length (Decimal Inch) | 1.3800 |
Spring Rate Pounds per Inch (Pounds) | 20.7000 |
Maximum Work Load (N) | 38.11999893 |
Solid Height (mm) | 14.55 |
Solid Height (Decimal Inch) | 0.5730 |
Material | Stainless Steel |
Wire Size (mm) | 1.19 |
Wire Size (Decimal Inch) | 0.0470 |
