Associated Spring Raymond - 9.14mm OD, 1.14mm Wire, 1-1/4" Free Length, Compression Spring - 18.2 Lb Spring Rating, 33.58 N Max Work Load, Stainless Steel
Item #: 69049526
Brand: Associated Spring Raymond
Model #: C03600451250X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 9.14 |
| Outside Diameter (Decimal Inch) | 0.3600 |
| Free Length (mm) | 31-3/4 |
| Free Length (Decimal Inch) | 1-1/4 |
| Spring Rate Pounds per Inch (Pounds) | 18.2000 |
| Maximum Work Load (N) | 33.58000183 |
| Solid Height (mm) | 13.11 |
| Solid Height (Decimal Inch) | 0.5160 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.14 |
| Wire Size (Decimal Inch) | 0.0450 |
