Associated Spring Raymond - 9.14mm OD, 1.14mm Wire, 14.22mm Free Length, Compression Spring - 46.8 Lb Spring Rating, 33.58 N Max Work Load, Stainless Steel
Item #: 69049229
Brand: Associated Spring Raymond
Model #: C03600450560X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 9.14 |
| Outside Diameter (Decimal Inch) | 0.3600 |
| Free Length (mm) | 14.22 |
| Free Length (Decimal Inch) | 0.5600 |
| Spring Rate Pounds per Inch (Pounds) | 46.8000 |
| Maximum Work Load (N) | 33.58000183 |
| Solid Height (mm) | 6.86 |
| Solid Height (Decimal Inch) | 0.2700 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.14 |
| Wire Size (Decimal Inch) | 0.0450 |
