Associated Spring Raymond - 9.14mm OD, 1.2mm Wire, 1-3/4" Free Length, Compression Spring - 19.3 Lb Spring Rating, 57.87 N Max Work Load, Music Wire
Item #: 69048916
Brand: Associated Spring Raymond
Model #: C03600471750M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 9.14 |
| Outside Diameter (Decimal Inch) | 0.3600 |
| Free Length (mm) | 44.45 |
| Free Length (Decimal Inch) | 1-3/4 |
| Spring Rate Pounds per Inch (Pounds) | 19.3000 |
| Maximum Work Load (N) | 57.86999893 |
| Solid Height (mm) | 17.70 |
| Solid Height (Decimal Inch) | 0.6970 |
| Material | Music Wire |
| Wire Size (mm) | 1.19 |
| Wire Size (Decimal Inch) | 0.0470 |
