Associated Spring Raymond - 9.14mm OD, 1.02mm Wire, 23.88mm Free Length, Compression Spring - 15.99 Lb Spring Rating, 24.33 N Max Work Load, Stainless Steel
Item #: 69048502
Brand: Associated Spring Raymond
Model #: C03600400940S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 9.14 |
| Outside Diameter (Decimal Inch) | 0.3600 |
| Free Length (mm) | 23.88 |
| Free Length (Decimal Inch) | 0.9400 |
| Spring Rate Pounds per Inch (Pounds) | 15.9900 |
| Maximum Work Load (N) | 24.32999992 |
| Solid Height (mm) | 8.97 |
| Solid Height (Decimal Inch) | 0.3530 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.02 |
| Wire Size (Decimal Inch) | 0.0400 |
