Associated Spring Raymond - 9.14mm OD, 1.02mm Wire, 11.18mm Free Length, Compression Spring - 46 Lb Spring Rating, 37.01 N Max Work Load, Music Wire
Item #: 69048338
Brand: Associated Spring Raymond
Model #: C03600400440M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 9.14 |
| Outside Diameter (Decimal Inch) | 0.3600 |
| Free Length (mm) | 11.18 |
| Free Length (Decimal Inch) | 0.4400 |
| Spring Rate Pounds per Inch (Pounds) | 46.0000 |
| Maximum Work Load (N) | 37.00999832 |
| Solid Height (mm) | 5.54 |
| Solid Height (Decimal Inch) | 0.2180 |
| Material | Music Wire |
| Wire Size (mm) | 1.02 |
| Wire Size (Decimal Inch) | 0.0400 |
