Associated Spring Raymond - 9.14mm OD, 0.97mm Wire, 28.45mm Free Length, Compression Spring - 12.9 Lb Spring Rating, 33.94 N Max Work Load, Music Wire
Item #: 69048122
Brand: Associated Spring Raymond
Model #: C03600381120M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 9.14 |
| Outside Diameter (Decimal Inch) | 0.3600 |
| Free Length (mm) | 28.45 |
| Free Length (Decimal Inch) | 1.1200 |
| Spring Rate Pounds per Inch (Pounds) | 12.9000 |
| Maximum Work Load (N) | 33.93999863 |
| Solid Height (mm) | 9.40 |
| Solid Height (Decimal Inch) | 0.3700 |
| Material | Music Wire |
| Wire Size (mm) | 0.97 |
| Wire Size (Decimal Inch) | 0.0380 |
