Associated Spring Raymond - 9.14mm OD, 0.81mm Wire, 25.4mm Free Length, Compression Spring - 8.5 Lb Spring Rating, 21 N Max Work Load, Music Wire - Americas Industrial Supply

Associated Spring Raymond - 9.14mm OD, 0.81mm Wire, 25.4mm Free Length, Compression Spring - 8.5 Lb Spring Rating, 21 N Max Work Load, Music Wire


Item #: 69047272
Brand: Associated Spring Raymond
Model #: C03600321000M
Exact Tooling IR#: 04

Product Specifications
Type Compression
Outside Diameter (mm) 9.14
Outside Diameter (Decimal Inch) 0.3600
Free Length (mm) 25.40
Free Length (Decimal Inch) 1
Spring Rate Pounds per Inch (Pounds) 8.5000
Maximum Work Load (N) 21
Solid Height (mm) 6.27
Solid Height (Decimal Inch) 0.2470
Material Music Wire
Wire Size (mm) 0.81
Wire Size (Decimal Inch) 0.0320
$1.75
