Associated Spring Raymond - 9.14mm OD, 0.81mm Wire, 23.88mm Free Length, Compression Spring - 7.8 Lb Spring Rating, 12.59 N Max Work Load, Stainless Steel
Item #: 69047256
Brand: Associated Spring Raymond
Model #: C03600320940X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 9.14 |
| Outside Diameter (Decimal Inch) | 0.3600 |
| Free Length (mm) | 23.88 |
| Free Length (Decimal Inch) | 0.9400 |
| Spring Rate Pounds per Inch (Pounds) | 7.8000 |
| Maximum Work Load (N) | 12.59000015 |
| Solid Height (mm) | 5.87 |
| Solid Height (Decimal Inch) | 0.2310 |
| Material | Stainless Steel |
| Wire Size (mm) | 0.81 |
| Wire Size (Decimal Inch) | 0.0320 |
