Associated Spring Raymond - 9.14mm OD, 0.74mm Wire, 1-3/4" Free Length, Compression Spring - 2.8 Lb Spring Rating, 9.43 N Max Work Load, Stainless Steel
Item #: 69047017
Brand: Associated Spring Raymond
Model #: C03600291750X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 9.14 |
| Outside Diameter (Decimal Inch) | 0.3600 |
| Free Length (mm) | 44.45 |
| Free Length (Decimal Inch) | 1-3/4 |
| Spring Rate Pounds per Inch (Pounds) | 2.8000 |
| Maximum Work Load (N) | 9.43000031 |
| Solid Height (mm) | 8.33 |
| Solid Height (Decimal Inch) | 0.3280 |
| Material | Stainless Steel |
| Wire Size (mm) | 0.74 |
| Wire Size (Decimal Inch) | 0.0290 |
