Associated Spring Raymond - 9.14mm OD, 0.66mm Wire, 22.35mm Free Length, Compression Spring - 4.1 Lb Spring Rating, 6.81 N Max Work Load, Stainless Steel
Item #: 69046548
Brand: Associated Spring Raymond
Model #: C03600260880X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 9.14 |
| Outside Diameter (Decimal Inch) | 0.3600 |
| Free Length (mm) | 22.35 |
| Free Length (Decimal Inch) | 0.8800 |
| Spring Rate Pounds per Inch (Pounds) | 4.1000 |
| Maximum Work Load (N) | 6.80999994 |
| Solid Height (mm) | 4.11 |
| Solid Height (Decimal Inch) | 0.1620 |
| Material | Stainless Steel |
| Wire Size (mm) | 0.66 |
| Wire Size (Decimal Inch) | 0.0260 |
