Associated Spring Raymond - 7.62mm OD, 1.2mm Wire, 17.53mm Free Length, Compression Spring - 63.56 Lb Spring Rating, 44.66 N Max Work Load, Stainless Steel
Item #: 69045086
Brand: Associated Spring Raymond
Model #: C03000470690S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 7.62 |
| Outside Diameter (Decimal Inch) | 0.3000 |
| Free Length (mm) | 17.53 |
| Free Length (Decimal Inch) | 0.6900 |
| Spring Rate Pounds per Inch (Pounds) | 63.5600 |
| Maximum Work Load (N) | 44.65999985 |
| Solid Height (mm) | 10.36 |
| Solid Height (Decimal Inch) | 0.4080 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.19 |
| Wire Size (Decimal Inch) | 0.0470 |
