Associated Spring Raymond - 7.62mm OD, 1.14mm Wire, 2-1/2" Free Length, Compression Spring - 12.99 Lb Spring Rating, 39.41 N Max Work Load, Stainless Steel
Item #: 69044915
Brand: Associated Spring Raymond
Model #: C03000452500S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 7.62 |
| Outside Diameter (Decimal Inch) | 0.3000 |
| Free Length (mm) | 63-1/2 |
| Free Length (Decimal Inch) | 2-1/2 |
| Spring Rate Pounds per Inch (Pounds) | 12.9900 |
| Maximum Work Load (N) | 39.40999985 |
| Solid Height (mm) | 29.72 |
| Solid Height (Decimal Inch) | 1.1700 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.14 |
| Wire Size (Decimal Inch) | 0.0450 |
