Associated Spring Raymond - 7.62mm OD, 1.3mm Wire, 22.35mm Free Length, Compression Spring - 67.5 Lb Spring Rating, 55.64 N Max Work Load, Stainless Steel
Item #: 69043529
Brand: Associated Spring Raymond
Model #: C03000510880X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 7.62 |
| Outside Diameter (Decimal Inch) | 0.3000 |
| Free Length (mm) | 22.35 |
| Free Length (Decimal Inch) | 0.8800 |
| Spring Rate Pounds per Inch (Pounds) | 67.5000 |
| Maximum Work Load (N) | 55.63999939 |
| Solid Height (mm) | 13.97 |
| Solid Height (Decimal Inch) | 0.5500 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.30 |
| Wire Size (Decimal Inch) | 0.0510 |
