Associated Spring Raymond - 9.14mm OD, 1.02mm Wire, 2-1/4" Free Length, Compression Spring - 6.33 Lb Spring Rating, 24.33 N Max Work Load, Stainless Steel
Item #: 69042877
Brand: Associated Spring Raymond
Model #: C03600402250S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 9.14 |
| Outside Diameter (Decimal Inch) | 0.3600 |
| Free Length (mm) | 57.15 |
| Free Length (Decimal Inch) | 2-1/4 |
| Spring Rate Pounds per Inch (Pounds) | 6.3300 |
| Maximum Work Load (N) | 24.32999992 |
| Solid Height (mm) | 18.01 |
| Solid Height (Decimal Inch) | 0.7090 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.02 |
| Wire Size (Decimal Inch) | 0.0400 |
