Associated Spring Raymond - 9.14mm OD, 1.2mm Wire, 50.8mm Free Length, Compression Spring - 13.99 Lb Spring Rating, 37.9 N Max Work Load, Stainless Steel
Item #: 69042661
Brand: Associated Spring Raymond
Model #: C03600472000S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 9.14 |
| Outside Diameter (Decimal Inch) | 0.3600 |
| Free Length (mm) | 50.80 |
| Free Length (Decimal Inch) | 2 |
| Spring Rate Pounds per Inch (Pounds) | 13.9900 |
| Maximum Work Load (N) | 37.90000153 |
| Solid Height (mm) | 19.84 |
| Solid Height (Decimal Inch) | 0.7810 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.19 |
| Wire Size (Decimal Inch) | 0.0470 |
