Associated Spring Raymond - 9.14mm OD, 1.24mm Wire, 25.4mm Free Length, Compression Spring - 34.32 Lb Spring Rating, 42.79 N Max Work Load, Stainless Steel
Item #: 69042406
Brand: Associated Spring Raymond
Model #: C03600491000S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 9.14 |
| Outside Diameter (Decimal Inch) | 0.3600 |
| Free Length (mm) | 25.40 |
| Free Length (Decimal Inch) | 1 |
| Spring Rate Pounds per Inch (Pounds) | 34.3200 |
| Maximum Work Load (N) | 42.79000092 |
| Solid Height (mm) | 12.04 |
| Solid Height (Decimal Inch) | 0.4740 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.24 |
| Wire Size (Decimal Inch) | 0.0490 |
