Associated Spring Raymond - 9.14mm OD, 1.3mm Wire, 2-3/4" Free Length, Compression Spring - 13.49 Lb Spring Rating, 47.68 N Max Work Load, Stainless Steel
Item #: 69042299
Brand: Associated Spring Raymond
Model #: C03600512750S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 9.14 |
| Outside Diameter (Decimal Inch) | 0.3600 |
| Free Length (mm) | 69.85 |
| Free Length (Decimal Inch) | 2-3/4 |
| Spring Rate Pounds per Inch (Pounds) | 13.4900 |
| Maximum Work Load (N) | 47.68000031 |
| Solid Height (mm) | 30.28 |
| Solid Height (Decimal Inch) | 1.1920 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.30 |
| Wire Size (Decimal Inch) | 0.0510 |
