Associated Spring Raymond - 9.14mm OD, 1.5mm Wire, 11.18mm Free Length, Compression Spring - 238 Lb Spring Rating, 108.22 N Max Work Load, Music Wire
Item #: 69042174
Brand: Associated Spring Raymond
Model #: C03600590440M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 9.14 |
| Outside Diameter (Decimal Inch) | 0.3600 |
| Free Length (mm) | 11.18 |
| Free Length (Decimal Inch) | 0.4400 |
| Spring Rate Pounds per Inch (Pounds) | 238.0000 |
| Maximum Work Load (N) | 108.22000122 |
| Solid Height (mm) | 8.15 |
| Solid Height (Decimal Inch) | 0.3210 |
| Material | Music Wire |
| Wire Size (mm) | 1-1/2 |
| Wire Size (Decimal Inch) | 0.0590 |
