Associated Spring Raymond - 9.14mm OD, 1.5mm Wire, 2-1/2" Free Length, Compression Spring - 26.8 Lb Spring Rating, 70.5 N Max Work Load, Stainless Steel
Item #: 69042133
Brand: Associated Spring Raymond
Model #: C03600592500X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 9.14 |
| Outside Diameter (Decimal Inch) | 0.3600 |
| Free Length (mm) | 63-1/2 |
| Free Length (Decimal Inch) | 2-1/2 |
| Spring Rate Pounds per Inch (Pounds) | 26.8000 |
| Maximum Work Load (N) | 70-1/2 |
| Solid Height (mm) | 34.24 |
| Solid Height (Decimal Inch) | 1.3480 |
| Material | Stainless Steel |
| Wire Size (mm) | 1-1/2 |
| Wire Size (Decimal Inch) | 0.0590 |
