Associated Spring Raymond - 10.67mm OD, 1.07mm Wire, 1/2" Free Length, Compression Spring - 28.32 Lb Spring Rating, 24.02 N Max Work Load, Stainless Steel
Item #: 69041911
Brand: Associated Spring Raymond
Model #: C04200420500S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 10.67 |
| Outside Diameter (Decimal Inch) | 0.4200 |
| Free Length (mm) | 12.70 |
| Free Length (Decimal Inch) | 1/2 |
| Spring Rate Pounds per Inch (Pounds) | 28.3200 |
| Maximum Work Load (N) | 24.02000046 |
| Solid Height (mm) | 4.83 |
| Solid Height (Decimal Inch) | 0.1900 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.07 |
| Wire Size (Decimal Inch) | 0.0420 |
