Associated Spring Raymond - 10.67mm OD, 1.5mm Wire, 25.4mm Free Length, Compression Spring - 49.31 Lb Spring Rating, 61.69 N Max Work Load, Stainless Steel
Item #: 69041598
Brand: Associated Spring Raymond
Model #: C04200591000S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 10.67 |
| Outside Diameter (Decimal Inch) | 0.4200 |
| Free Length (mm) | 25.40 |
| Free Length (Decimal Inch) | 1 |
| Spring Rate Pounds per Inch (Pounds) | 49.3100 |
| Maximum Work Load (N) | 61.68999863 |
| Solid Height (mm) | 13.87 |
| Solid Height (Decimal Inch) | 0.5460 |
| Material | Stainless Steel |
| Wire Size (mm) | 1-1/2 |
| Wire Size (Decimal Inch) | 0.0590 |
