Associated Spring Raymond - 7.62mm OD, 1.02mm Wire, 35.05mm Free Length, Compression Spring - 17.4 Lb Spring Rating, 43.81 N Max Work Load, Music Wire
Item #: 69040574
Brand: Associated Spring Raymond
Model #: C03000401380M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 7.62 |
| Outside Diameter (Decimal Inch) | 0.3000 |
| Free Length (mm) | 35.05 |
| Free Length (Decimal Inch) | 1.3800 |
| Spring Rate Pounds per Inch (Pounds) | 17.4000 |
| Maximum Work Load (N) | 43.81000137 |
| Solid Height (mm) | 15.27 |
| Solid Height (Decimal Inch) | 0.6010 |
| Material | Music Wire |
| Wire Size (mm) | 1.02 |
| Wire Size (Decimal Inch) | 0.0400 |
