Associated Spring Raymond - 7.62mm OD, 1.02mm Wire, 1-1/4" Free Length, Compression Spring - 19.4 Lb Spring Rating, 43.81 N Max Work Load, Music Wire
Item #: 69040558
Brand: Associated Spring Raymond
Model #: C03000401250M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 7.62 |
| Outside Diameter (Decimal Inch) | 0.3000 |
| Free Length (mm) | 31-3/4 |
| Free Length (Decimal Inch) | 1-1/4 |
| Spring Rate Pounds per Inch (Pounds) | 19.4000 |
| Maximum Work Load (N) | 43.81000137 |
| Solid Height (mm) | 14.05 |
| Solid Height (Decimal Inch) | 0.5530 |
| Material | Music Wire |
| Wire Size (mm) | 1.02 |
| Wire Size (Decimal Inch) | 0.0400 |
