Associated Spring Raymond - 7.62mm OD, 1.02mm Wire, 20.57mm Free Length, Compression Spring - 25.8 Lb Spring Rating, 28.78 N Max Work Load, Stainless Steel
Item #: 69040426
Brand: Associated Spring Raymond
Model #: C03000400810X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 7.62 |
| Outside Diameter (Decimal Inch) | 0.3000 |
| Free Length (mm) | 20.57 |
| Free Length (Decimal Inch) | 0.8100 |
| Spring Rate Pounds per Inch (Pounds) | 25.8000 |
| Maximum Work Load (N) | 28.78000069 |
| Solid Height (mm) | 9.91 |
| Solid Height (Decimal Inch) | 0.3900 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.02 |
| Wire Size (Decimal Inch) | 0.0400 |
