Associated Spring Raymond - 7.62mm OD, 0.97mm Wire, 20.57mm Free Length, Compression Spring - 21.49 Lb Spring Rating, 24.82 N Max Work Load, Stainless Steel
Item #: 69039931
Brand: Associated Spring Raymond
Model #: C03000380810S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 7.62 |
| Outside Diameter (Decimal Inch) | 0.3000 |
| Free Length (mm) | 20.57 |
| Free Length (Decimal Inch) | 0.8100 |
| Spring Rate Pounds per Inch (Pounds) | 21.4900 |
| Maximum Work Load (N) | 24.81999969 |
| Solid Height (mm) | 8.92 |
| Solid Height (Decimal Inch) | 0.3510 |
| Material | Stainless Steel |
| Wire Size (mm) | 0.97 |
| Wire Size (Decimal Inch) | 0.0380 |
