Associated Spring Raymond - 7.62mm OD, 0.97mm Wire, 1/2" Free Length, Compression Spring - 46.4 Lb Spring Rating, 40.21 N Max Work Load, Music Wire
Item #: 69039816
Brand: Associated Spring Raymond
Model #: C03000380500M
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Compression |
Outside Diameter (mm) | 7.62 |
Outside Diameter (Decimal Inch) | 0.3000 |
Free Length (mm) | 12.70 |
Free Length (Decimal Inch) | 1/2 |
Spring Rate Pounds per Inch (Pounds) | 46.4000 |
Maximum Work Load (N) | 40.20999908 |
Solid Height (mm) | 6.02 |
Solid Height (Decimal Inch) | 0.2370 |
Material | Music Wire |
Wire Size (mm) | 0.97 |
Wire Size (Decimal Inch) | 0.0380 |
