Associated Spring Raymond - 7.62mm OD, 0.81mm Wire, 1-1/2" Free Length, Compression Spring - 7.1 Lb Spring Rating, 24.87 N Max Work Load, Music Wire
Item #: 69039196
Brand: Associated Spring Raymond
Model #: C03000321500M
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Compression |
Outside Diameter (mm) | 7.62 |
Outside Diameter (Decimal Inch) | 0.3000 |
Free Length (mm) | 38.10 |
Free Length (Decimal Inch) | 1-1/2 |
Spring Rate Pounds per Inch (Pounds) | 7.1000 |
Maximum Work Load (N) | 24.87000084 |
Solid Height (mm) | 11.43 |
Solid Height (Decimal Inch) | 0.4500 |
Material | Music Wire |
Wire Size (mm) | 0.81 |
Wire Size (Decimal Inch) | 0.0320 |
