Associated Spring Raymond - 7.62mm OD, 0.76mm Wire, 2-1/4" Free Length, Compression Spring - 3.1 Lb Spring Rating, 12.37 N Max Work Load, Stainless Steel
Item #: 69038875
Brand: Associated Spring Raymond
Model #: C03000302250X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 7.62 |
| Outside Diameter (Decimal Inch) | 0.3000 |
| Free Length (mm) | 57.15 |
| Free Length (Decimal Inch) | 2-1/4 |
| Spring Rate Pounds per Inch (Pounds) | 3.1000 |
| Maximum Work Load (N) | 12.36999989 |
| Solid Height (mm) | 14.35 |
| Solid Height (Decimal Inch) | 0.5650 |
| Material | Stainless Steel |
| Wire Size (mm) | 0.76 |
| Wire Size (Decimal Inch) | 0.0300 |
