Associated Spring Raymond - 7.62mm OD, 0.76mm Wire, 17.53mm Free Length, Compression Spring - 13 Lb Spring Rating, 19.66 N Max Work Load, Music Wire
Item #: 69038610
Brand: Associated Spring Raymond
Model #: C03000300690M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 7.62 |
| Outside Diameter (Decimal Inch) | 0.3000 |
| Free Length (mm) | 17.53 |
| Free Length (Decimal Inch) | 0.6900 |
| Spring Rate Pounds per Inch (Pounds) | 13.0000 |
| Maximum Work Load (N) | 19.65999985 |
| Solid Height (mm) | 5.77 |
| Solid Height (Decimal Inch) | 0.2270 |
| Material | Music Wire |
| Wire Size (mm) | 0.76 |
| Wire Size (Decimal Inch) | 0.0300 |
