Associated Spring Raymond - 7.62mm OD, 0.56mm Wire, 15.75mm Free Length, Compression Spring - 5 Lb Spring Rating, 8.59 N Max Work Load, Music Wire
Item #: 69037836
Brand: Associated Spring Raymond
Model #: C03000220620M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 7.62 |
| Outside Diameter (Decimal Inch) | 0.3000 |
| Free Length (mm) | 15-3/4 |
| Free Length (Decimal Inch) | 0.6200 |
| Spring Rate Pounds per Inch (Pounds) | 5.0000 |
| Maximum Work Load (N) | 8.59000015 |
| Solid Height (mm) | 3.20 |
| Solid Height (Decimal Inch) | 0.1260 |
| Material | Music Wire |
| Wire Size (mm) | 0.56 |
| Wire Size (Decimal Inch) | 0.0220 |
