Associated Spring Raymond - 6.1mm OD, 1.14mm Wire, 1-3/4" Free Length, Compression Spring - 30.7 Lb Spring Rating, 48.13 N Max Work Load, Stainless Steel
Item #: 69037612
Brand: Associated Spring Raymond
Model #: C02400451750X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 6.10 |
| Outside Diameter (Decimal Inch) | 0.2400 |
| Free Length (mm) | 44.45 |
| Free Length (Decimal Inch) | 1-3/4 |
| Spring Rate Pounds per Inch (Pounds) | 30.7000 |
| Maximum Work Load (N) | 48.13000107 |
| Solid Height (mm) | 28.07 |
| Solid Height (Decimal Inch) | 1.1050 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.14 |
| Wire Size (Decimal Inch) | 0.0450 |
