Associated Spring Raymond - 6.1mm OD, 1.02mm Wire, 1-3/4" Free Length, Compression Spring - 17.9 Lb Spring Rating, 35.14 N Max Work Load, Stainless Steel
Item #: 69036622
Brand: Associated Spring Raymond
Model #: C02400401750X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 6.10 |
| Outside Diameter (Decimal Inch) | 0.2400 |
| Free Length (mm) | 44.45 |
| Free Length (Decimal Inch) | 1-3/4 |
| Spring Rate Pounds per Inch (Pounds) | 17.9000 |
| Maximum Work Load (N) | 35.13999939 |
| Solid Height (mm) | 24.82 |
| Solid Height (Decimal Inch) | 0.9770 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.02 |
| Wire Size (Decimal Inch) | 0.0400 |
