Associated Spring Raymond - 6.1mm OD, 0.97mm Wire, 50.8mm Free Length, Compression Spring - 15.1 Lb Spring Rating, 49.2 N Max Work Load, Music Wire
Item #: 69036309
Brand: Associated Spring Raymond
Model #: C02400382000M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 6.10 |
| Outside Diameter (Decimal Inch) | 0.2400 |
| Free Length (mm) | 50.80 |
| Free Length (Decimal Inch) | 2 |
| Spring Rate Pounds per Inch (Pounds) | 15.1000 |
| Maximum Work Load (N) | 49.20000076 |
| Solid Height (mm) | 26.21 |
| Solid Height (Decimal Inch) | 1.0320 |
| Material | Music Wire |
| Wire Size (mm) | 0.97 |
| Wire Size (Decimal Inch) | 0.0380 |
