Associated Spring Raymond - 6.1mm OD, 0.97mm Wire, 20.57mm Free Length, Compression Spring - 35.2 Lb Spring Rating, 30.29 N Max Work Load, Stainless Steel
Item #: 69036093
Brand: Associated Spring Raymond
Model #: C02400380810X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 6.10 |
| Outside Diameter (Decimal Inch) | 0.2400 |
| Free Length (mm) | 20.57 |
| Free Length (Decimal Inch) | 0.8100 |
| Spring Rate Pounds per Inch (Pounds) | 35.2000 |
| Maximum Work Load (N) | 30.29000092 |
| Solid Height (mm) | 11.07 |
| Solid Height (Decimal Inch) | 0.4360 |
| Material | Stainless Steel |
| Wire Size (mm) | 0.97 |
| Wire Size (Decimal Inch) | 0.0380 |
