Associated Spring Raymond - 6.1mm OD, 0.9mm Wire, 22.35mm Free Length, Compression Spring - 25.7 Lb Spring Rating, 37.1 N Max Work Load, Music Wire
Item #: 69035723
Brand: Associated Spring Raymond
Model #: C02400350880M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 6.10 |
| Outside Diameter (Decimal Inch) | 0.2400 |
| Free Length (mm) | 22.35 |
| Free Length (Decimal Inch) | 0.8800 |
| Spring Rate Pounds per Inch (Pounds) | 25.7000 |
| Maximum Work Load (N) | 37.09999847 |
| Solid Height (mm) | 11.30 |
| Solid Height (Decimal Inch) | 0.4450 |
| Material | Music Wire |
| Wire Size (mm) | 0.89 |
| Wire Size (Decimal Inch) | 0.0350 |
