Associated Spring Raymond - 6.1mm OD, 0.9mm Wire, 1/2" Free Length, Compression Spring - 48.5 Lb Spring Rating, 37.1 N Max Work Load, Music Wire
Item #: 69035590
Brand: Associated Spring Raymond
Model #: C02400350500M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 6.10 |
| Outside Diameter (Decimal Inch) | 0.2400 |
| Free Length (mm) | 12.70 |
| Free Length (Decimal Inch) | 1/2 |
| Spring Rate Pounds per Inch (Pounds) | 48.5000 |
| Maximum Work Load (N) | 37.09999847 |
| Solid Height (mm) | 7.26 |
| Solid Height (Decimal Inch) | 0.2860 |
| Material | Music Wire |
| Wire Size (mm) | 0.89 |
| Wire Size (Decimal Inch) | 0.0350 |
