Associated Spring Raymond - 6.1mm OD, 0.74mm Wire, 50.8mm Free Length, Compression Spring - 5.3 Lb Spring Rating, 22.02 N Max Work Load, Music Wire
Item #: 69035046
Brand: Associated Spring Raymond
Model #: C02400292000M
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Compression |
Outside Diameter (mm) | 6.10 |
Outside Diameter (Decimal Inch) | 0.2400 |
Free Length (mm) | 50.80 |
Free Length (Decimal Inch) | 2 |
Spring Rate Pounds per Inch (Pounds) | 5.3000 |
Maximum Work Load (N) | 22.02000046 |
Solid Height (mm) | 17.22 |
Solid Height (Decimal Inch) | 0.6780 |
Material | Music Wire |
Wire Size (mm) | 0.74 |
Wire Size (Decimal Inch) | 0.0290 |
