Associated Spring Raymond - 6.1mm OD, 0.74mm Wire, 15.75mm Free Length, Compression Spring - 18.4 Lb Spring Rating, 22.02 N Max Work Load, Music Wire
Item #: 69034742
Brand: Associated Spring Raymond
Model #: C02400290620M
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Compression |
Outside Diameter (mm) | 6.10 |
Outside Diameter (Decimal Inch) | 0.2400 |
Free Length (mm) | 15-3/4 |
Free Length (Decimal Inch) | 0.6200 |
Spring Rate Pounds per Inch (Pounds) | 18.4000 |
Maximum Work Load (N) | 22.02000046 |
Solid Height (mm) | 6.55 |
Solid Height (Decimal Inch) | 0.2580 |
Material | Music Wire |
Wire Size (mm) | 0.74 |
Wire Size (Decimal Inch) | 0.0290 |
