Associated Spring Raymond - 6.1mm OD, 0.51mm Wire, 1/4" Free Length, Compression Spring - 14.1 Lb Spring Rating, 7.78 N Max Work Load, Music Wire
Item #: 69033074
Brand: Associated Spring Raymond
Model #: C02400200250M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 6.10 |
| Outside Diameter (Decimal Inch) | 0.2400 |
| Free Length (mm) | 6.35 |
| Free Length (Decimal Inch) | 1/4 |
| Spring Rate Pounds per Inch (Pounds) | 14.1000 |
| Maximum Work Load (N) | 7.78000021 |
| Solid Height (mm) | 2.31 |
| Solid Height (Decimal Inch) | 0.0910 |
| Material | Music Wire |
| Wire Size (mm) | 0.51 |
| Wire Size (Decimal Inch) | 0.0200 |
