Profiling Insert: RCMK152 KCU10B, .251" Thick, 3/16" Inscribed Circle
Item #: 82161084
Brand: Kennametal
Model #: 7096365
Product Specifications
| Insert Style | RCMK |
| Insert Size Code | 46 |
| Insert Material | Carbide |
| Manufacturer Grade | KCU10B |
| Thickness (Inch) | .251 |
| Insert Height (Decimal Inch) | 0.2510 |
| Thickness (mm) | 6.3800 |
| Insert Height (mm) | 6.38 |
| Maximum Depth of Cut (Decimal Inch) | 0.0938 |
| Maximum Depth of Cut (mm) | 2.38 |
| Insert Holding Method | Pin |
| Insert Hand | Neutral |
| Corner Radius (Decimal Inch) | 0.0937 |
| Corner Radius (mm) | 2.38 |
| Included Angle | 0.00 |
| Relief Angle | 7.500 |
| Inscribed Circle (Inch) | 3/16 |
| Inscribed Circle (Decimal Inch) | 0.1875 |
| Inscribed Circle (mm) | 4.76 |
| Coating Process | PVD |
| Number Of Cutting Edges | 6 |
| Iso Code | RCMK040300 |
| Rake Angle | 7.500 |
| Coating/Finish | AlTiN |
| Thickness (Decimal Inch - 4 Decimals) | 0.2510 |
| Width (Decimal Inch - 4 Decimals) | 0.2500 |
| Width (mm - 2 Decimals) | 6.38 |
| UNSPSC Code | 23242105 |
