Electro Hardware - #10-32, 1-3/8" OAL, 1/4" Across Flats, Brass Hex Male/Female Circuit Board Standoffs - 1/2" Thread Depth, 1" Body Length, Zinc-Plated Finish
Item #: 67738245
Brand: Electro Hardware
Model #: 1451M03F21-1032
Exact Tooling IR#: 04
Features and Benefits
Circuit board standoffs with male/female threads have one externally threaded end and one internally threaded end. The female end accepts male fasteners or other standoffs.
Brass is an alloy of copper and zinc that is durable, nonmagnetic and conductive.
| Product Specifications | |
|---|---|
| Thread Type | Male/Female |
| Material | Brass |
| System of Measurement | Inch |
| Body Shape | Hex |
| Overall Length (Inch) | 1-3/8 |
| Overall Length (Decimal Inch) | 1.3750 |
| Thread Size | #10-32 |
| Width Across Flats (Decimal Inch) | 0.2500 |
| Width Across Flats (Inch) | 1/4 |
| Finish/Coating | Zinc-Plated |
| Body Length (Inch) | 1 |
| Body Length (Decimal Inch) | 1.0000 |
| Thread Length (Inch) | 3/8 |
| Thread Depth (Inch) | 1/2 |
| Length Tolerance (Decimal Inch) | -0.005 to 0.005 |
| Fastener Standard | ASTM B633 Type 1; QQ-B-626 Comp 22 |
