Electro Hardware - #4-40, 1" OAL, Steel Round Fully Threaded Female Circuit Board Standoffs - 1" Thread Depth, 1" Body Length, Zinc-Plated Clear Chromate Finish
Item #: 67718601
Brand: Electro Hardware
Model #: P561M10F21-440
Exact Tooling IR#: 04
Features and Benefits
Circuit board standoffs with female threads are internally threaded to accept male fasteners or other standoffs. They are internally threaded on one end.
Steel is strong and durable but less corrosion resistant than stainless steel. To improve its resistance to corrosion, it may receive additional finishes and coatings.
| Product Specifications | |
|---|---|
| Thread Type | Female |
| Material | Steel |
| System of Measurement | Inch |
| Body Shape | Round |
| Overall Length (Inch) | 1 |
| Overall Length (Decimal Inch) | 1.0000 |
| Thread Style | Fully Threaded |
| Thread Size | #4-40 |
| Finish/Coating | Zinc-Plated Clear Chromate |
| Outside Diameter (Inch) | 1/4 |
| Outside Diameter (Decimal Inch) | 0.2500 |
| Body Length (Inch) | 1 |
| Thread Depth (Inch) | 1 |
| Length Tolerance (Decimal Inch) | -0.005 to 0.005 |
| Material Grade | Grade 2 |
| Fastener Standard | ASTM B633 Type 1; QQ-S-633 |
