Heli-Coil - Screw-Locking Inserts; Thread Size: M4x0.70 ; Overall Insert Length (mm): 6.00 ; Tang: Yes ; Tang: Tangless ; Length to Diameter Ratio: 1-1/2D ; Length to Diameter Ratio: 1-1/2D
Item #: 67701136
Brand: Heli-Coil
Model #: 4184-4CNW060S
Product Specifications
Screw-Locking Inserts; Thread Size: M4x0.70 ; Overall Insert Length (mm): 6.00 ; Tang: Yes ; Tang: Tangless ; Length to Diameter Ratio: 1-1/2D ; Length to Diameter Ratio: 1-1/2D
| Thread Size | M4x0.70 |
| Overall Insert Length (mm) | 6.00 |
| Tang | Yes |
| Tang | Tangless |
| Length to Diameter Ratio | 1-1/2D |
| Number of Inserts | 1,000 |
| Material | Stainless Steel |
| Minimum Outside Diameter (mm) | 5.05 |
| Maximum Outside Diameter (mm) | 5.60 |
| Finish/Coating | Dry Film Lubricant |
| Number of Free Coils | 6-1/8 |
| Maximum Locking Torque (N/m) | 0.90 |
| Minimum Break Away Torque (N/m) | 0.1600 |
| Thread Standard | Metric Coarse |
| Material Grade | 304 |
