Associated Spring Raymond - 10.67mm OD, 1.83mm Wire, 2-1/2" Free Length, Compression Spring - 42.15 Lb Spring Rating, 106.22 N Max Work Load, Stainless Steel
Item #: 67700062
Brand: Associated Spring Raymond
Model #: C04200722500S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 10.67 |
| Outside Diameter (Decimal Inch) | 0.4200 |
| Free Length (mm) | 63-1/2 |
| Free Length (Decimal Inch) | 2-1/2 |
| Spring Rate Pounds per Inch (Pounds) | 42.1500 |
| Maximum Work Load (N) | 106.22000122 |
| Solid Height (mm) | 38.63 |
| Solid Height (Decimal Inch) | 1.5210 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.83 |
| Wire Size (Decimal Inch) | 0.0720 |
