Value Collection - 1" Bolt, 1-1/16" ID, Steel, Uncoated, Belleville Disc Spring - 1-1/2" OD
Item #: 67496166
Brand: Value Collection
Exact Tooling IR#: 04
Features and Benefits
Belleville disc springs, also known as conical washers, have a curved shape that creates a spring-like action. They are used in applications that require heavy loads.
| Product Specifications | |
|---|---|
| Type | Belleville Disc Spring |
| Bolt Size (Inch) | 1 |
| System of Measurement | Inch |
| Inside Diameter (Decimal Inch) | 1.0630 |
| Material | Steel |
| Outside Diameter (Decimal Inch) | 1.4960 |
| Minimum Inside Diameter (Decimal Inch) | 1.0630 |
| Maximum Outside Diameter (Decimal Inch) | 1.4960 |
| Maximum Thickness (Decimal Inch) | 0.0790 |
| Finish/Coating | Uncoated |
