Associated Spring Raymond - 9.14mm OD, 1.14mm Wire, 22.35mm Free Length, Compression Spring - 32.8 Lb Spring Rating, 53.78 N Max Work Load, Music Wire
Item #: 66564287
Brand: Associated Spring Raymond
Model #: C03600450880M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 9.14 |
| Outside Diameter (Decimal Inch) | 0.3600 |
| Free Length (mm) | 22.35 |
| Free Length (Decimal Inch) | 0.8800 |
| Spring Rate Pounds per Inch (Pounds) | 32.8000 |
| Maximum Work Load (N) | 53.77999878 |
| Solid Height (mm) | 9.70 |
| Solid Height (Decimal Inch) | 0.3820 |
| Material | Music Wire |
| Wire Size (mm) | 1.14 |
| Wire Size (Decimal Inch) | 0.0450 |
