WOHLHAUPTER - 65mm Body Diam, Manual Single Cutter Boring Head - 3mm to 208mm Bore Diam, 17mm Bar Hole Diam
Item #: 66310061
Brand: WOHLHAUPTER
Model #: 501005
Exact Tooling IR#: 04
Features and Benefits
Boring heads with a single cutter (single edge) are used for general purpose finishing and roughing operations. They may also be used where machine power is limited.
Integral shank boring heads have the shank built into the head.
| Product Specifications | |
|---|---|
| Type | Single Cutter Boring Head |
| Actuation Type | Manual |
| Body Diameter (mm) | 65.00 |
| Body Diameter (Decimal Inch) | 2.5590 |
| Mount Type | Integral Shank |
| Shank Type | Modular Connection |
| Shank Diameter (Decimal Inch) | 1.9680 |
| Modular Connection Size | MVS50-28 |
| Series | Digibore |
| Boring Bar Hole Diameter (mm) | 17.00 |
| Boring Bar Hole Diameter (Decimal Inch) | 0.6690 |
| Minimum Bore Diameter (Decimal Inch) | 0.1180 |
| Minimum Bore Diameter (mm) | 3.00 |
| Maximum Bore Diameter (mm) | 208.00 |
| Maximum Bore Diameter (Decimal Inch) | 8.1890 |
| Projection (mm) | 60.00 |
| Projection (Decimal Inch) | 2.3620 |
| Overall Length (mm) | 60.00 |
| Overall Length (Decimal Inch) | 2.3620 |
| Travel Size (Decimal Inch) | 0.3040 |
| Diameter Direct Reading (Decimal Inch) | 0.0001 |
| Machine Compatibility | CNC; Manual |
| Insert Holder Size | 06 |
| Rate of Feed (Decimal Inch) | 0.0060 |
